YE100BWK

Structural Priciple

Instrument from the measuring system (including joints, bellows, etc.), transmission, indicating
When measured media pressure acting on the diaphragm. The free end of a corresponding elasticdevices and enclosure components.deformation - displacement, Pull rod drive mechanism driven by the amplification. Pressure will bemeasured by the indicating device is indicated on the dashboard.

Work location, environment: instrumentation installed vertically, the working environmenttemperature -25 . 55 ℃, relative humidity less than 80%, and ambient air does not contain harmful
gases corrode the instrument.Temperature effect: When the temperature deviation from 20 + 5 'C, the temperature of theadditional error of less than 0.4%/10 ℃
